    Trailer Mounted Diesel Generator 50KW 62.5KVA Electric

    Ask Lasest Price
    Brand Name : CNMC
    Model Number : CN50GF
    Certification : EPA/CE/ISO
    Price : USD 2500-3000/set
    Payment Terms : L/C, T/T
    Supply Ability : 1000 sets per week
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    Trailer Mounted Diesel Generator 50KW 62.5KVA Electric

    Hot Sale Chinese Factory Producing Trailer Type 50 KW 62.5 KVA Diesel Generator Set


    Main Assemblies:

    • 1, Diesel Engine (Cummins Brand)
    • 2, Generator/Alternator (With AVR)
    • 3, Standard Control Panel (Ordinary Type, LCD Type, ATS Type )
    • 4, Common Base with Canopy(Including Base Oil Tank)

    Standard Accessories:

    • 1, Starting Battery and Connector Wire
    • 2, The Vibration Reduction Rubber Gasket
    • 3, Silencer
    • 4, Exhaust Elbow
    • 5, 8-hour Oil Tank
    • 6, Spare Part Case
    • 7, Technical Data
    • 8, Water Tank Radiator,The belt-driving Cooling Fan ,Fan Safety Shield
    • 9, Dry-type Air Filter
    • 10, Fuel Filter
    • 11, Lubricating Oil Filter
    • 12, Starting Motor
    • 13, Self-charging Generator
    • 14, Frequency Meter/Water-thermometer/Oil Pressure Gauge/Battery Voltmeter

    Optional Accessories:

    • 1, Preheating Start System
    • 2, Diesel Engine Thermal Protection System
    • 3, Jacket Heater
    • 4, Speeding, High Temperature, High Oil Temperature, Low Pressure Alarm System
    • 5, Breaker
    • 6, Antifreeze Liquid
    • 7, Ground Wire
    • 8, Water Temperature Safety Device
    • 9, Machine Oil

    Service Conditions:

    • -- Ambient Temperature: -25°C~40°C
    • -- Altitude: not exceed 1000 Meter
    • -- Rated Voltage: 230/380V or any voltage between 220-440V
    • -- Rated Frequency: 50Hz/60Hz
    • -- Insulation Class: B/F/H
    • -- Working Duty: S1(Continuous)
    • -- Humidity: Lower than 95%
    ModelCN50GF
    Standby PowerKVA68.75
    KW55
    Prime PowerKVA62.5
    KW50
    FrequencyHz50
    VoltageV230/400
    Rated speedrpm1500
    Cummins 4BTA3.9-G2: in-line, 4 cylinder, 4 cycle, turbocharged and after-cooler diesel engine
    Bore X Stroke (mm)102x120
    Displacement (L)3.9
    Compression ratio16.5:1
    Rated speed (rpm)1500/1800
    Prime power (kW)50/60
    Standby power (kW)55/65
    Fuel injection pumpAD injection pump
    GovernorGAC electric governor / RSV mechanical governor
    Steady speed droop≤1% (Electrical governor) / ≤5% (Mechanical governor)
    Lubricant capacity (L)11
    Coolant capacity (L)7.9 (engine only)
    Net weight (kg)350
    Gross weigh (kg)370
    Overall dimension (LXWXH) (mm)765X582X908
    Coolant intake size¢58 mm
    Coolant outlet size¢45 mm
    Flywheel/Flywheel housingSAE3#/ SAE3#
    Cooling systemForced water cooling cycle
    Performance data
    Standard air intake temperature25℃
    Air intake pressure (kPa)100
    Standard light diesel0# / -10# light diesel
    Fuel intake temperature40
    Air intake restriction (mmHg)251
    Exhaust back pressure (mmHg)76
    Lubrication oil15W40-CF4 Upgrade
