    50Hz 60Hz Fog Cannon Sprayer Machine Stainless Steel Material

    Ask Lasest Price
    Brand Name : CNMC
    Model Number : CN30
    Certification : CE
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 100set one week
    Delivery Time : 5-8work day
    • Product Details
    • Company Profile

    50Hz 60Hz Fog Cannon Sprayer Machine Stainless Steel Material

    30m Fog Cannon Sprayer Factory Sales Adjusted With Chassis Water Fog Sprayer Cannon Machine

    Products Description


    • 1. Added automatic reset function When the sprayer is stopped, it will automatically reset to the initial position, saving the personnel to adjust again, and convenient for transportation and placement.


      2. the automatic drain function is added. When the sprayer is not used for a long time, the drain solenoid valve will automatically open to drain the water in the pump to prevent the pump from freezing in winter.


      3. The design of the power distribution cabinet is light; the external wiring is connected by aviation plug, which is safe, firm, beautiful, elegant and fashionable.


      4. The supporting power is flexible, that is, it can be powered by three-phase 380V mains or diesel generator set.


      5. It can be fixedly installed on the platform where the concrete is poured, and can also be installed on the transportation vehicle with the power supply of the diesel generator set; it can also be used together with the sprinkler.


    50Hz 60Hz Fog Cannon Sprayer Machine Stainless Steel Material


    ModelTDM-M03
    Spray range30m
    Total power10kw
    Water consumption3000L/H
    L*W*H1550*1030*1600mm
    Weight520kg
    Control MethodElectric control (no PLC)
    IP GradeIP55
    Noise Level70dB at 7.5m
    Turning degreeLeft:180/Right:180
    Pitching degreeUp:50/Down:-10
    Diameter of water mist particle20-150µm
    Fan power5.5kw
    Water pump power2.2kw
    Water pump pressure1-1.5Mpa
    Usage temperature(℃)0-50
    Power supplyAC/3-phase/380V/50HZ
    Nozzles quantity36pcs
    Generator set12KW

    50Hz 60Hz Fog Cannon Sprayer Machine Stainless Steel Material50Hz 60Hz Fog Cannon Sprayer Machine Stainless Steel Material
